Chapter
9,Determining the number of cavities(Textbook for plastic injection mold
design)
Home » Mould Technology Blog » News Center » Chapter 9,Determining the number of
cavities(Textbook for plastic injection mold design)
Factors involved
The number of
cavities depends on the available production time, product quantity
required,
machine shot size and plasticizing capacities, shape and size of the
moldings,
and mold costs.
Formulas
Following are
simple formulas for determining the number of cavities. Use the minimum
value
derived from the following formulas.
Product quantity
If the dimensional tolerance
of the part is not very critical and a large number of moldings are
required,
multi-cavity molds are preferred. The number of cavities is dependent on the
time
available to supply a specific lot of parts ™, the number of parts in
the lot (L), the cycle time to
produce a single set of parts (tc), the reject
factor (K), expressed as K = 1/(1-reject rate). The
relation is:
Number of
cavities = L x K x tc / tm
Shot
capacity
The injection machine shot capacity is also a factor in
determining the number of cavities. Take 80
percent of the machine capacity
as the shot weight (S) and divide by the part weight (W) to get the
number of
cavities. The relation is:
Number of cavities = S / W
Plasticizing capacity
The injection machine
plasticizing capacity is also a factor. Divide the plasticizing capacity (P)
of
the machine by the estimated number of shots per minute (X) and part
weight (W). The relation is:
Number of cavities = P / ( X x W
)
Determining Number of Cavities
